phone APP real-time query
no reagent needed
pH,ORP,TDS...
MT-W1100 Series Multi-parameter Water Quality Analyzer
Application：
Online monitoring of water quality of different water bodies such as tap water, surface water, groundwater, source water, drinking water, river water, river channel, ocean, sewage outlet, aquaculture, secondary water supply, etc.
Features：
> One system can measure multiple water quality parameters
1.Measurement parameters are optional, with high accuracy and good repeatability
2.Sensors can be combined arbitrarily, installation is simple and easy, maintenance is convenient.
3.No reagents need to be added, no reagent consumption will not cause secondary pollution, no waste liquid.
4.Automatic compensation of electrodes within a certain range.
5.Multiple output modes are optional (4...20mA, RS 485 MODBUS-RTU, GPRS, Ethernet port)
6.Can be connected through wireless 4G network card, WiFi connection, Ethernet connection to achieve remote computer monitoring and mobile phone APP real-time query.
7.Can be equipped with a variety of reverse control functions to achieve on-site equipment online operation.
8.7 inch,10inch...intelligent touch screen for option.
9.Wall-mounted, pulley lock...installation methods for option.
Technical Parameters:
pH: | Testing range: -2.00 ~ 16.00pH Resolution: 0.01pH Testing accuracy: +/-0.01pH Temperature compensation: automatic or manual |
ORP redox: | Testing range: -2000 ~ 2000mV Resolution: 1mV Testing accuracy: +/-1mV |
DO dissolved oxygen: | Testing range: 0.00 ~ 400%, 0.00 ~ 40.00mg/L Resolution: 0.1%, 0.01mg/L Testing accuracy: +/-0.2%FS Temperature compensation: automatic or manual |
EC Resolution Ratio: | Testing range: 0.00 uS/cm ~ 20.00mS/cm Resolution: 0.01uS/cm ~ 0.01mS/cm Testing accuracy: +/-0.5%FS Temperature compensation: automatic or manual |
TDS Total dissolved solid: | Testing range: 0.00 ~ 20.00ppt Resolution: 0.01ppt Testing accuracy: +/-0.5%FS Temperature compensation: automatic or manual |
FCL Residual chlorine: | Testing range: 0.00 ~ 20.00mg/L Resolution: 0.01mg/L Testing accuracy: 2% or 10ppb take the max value Temperature compensation: automatic or manual |
SS Turbidity: | Testing range: 0 ~ 500NTU Resolution: 0.01NTU Testing accuracy: +/-1.0%FS |
MLSS Sludge concentration: | Testing range: 0 ~ 3000mg/L Resolution: mg/L Testing accuracy: +/-1.0%FS |
Temp: | Testing range: 0 ~ 100℃ Resolution: 0.2℃ Testing accuracy: +/-0.2℃ |
Current signal output | 4~20mA adjustable, load < 750Ω Supports up to 8 channels of simultaneous output |
Relay output: | Control: 8 SPST relays Load: 5A 250V AC/5A 30VDC |
Data communication: | RS485(Modbus) optional NB-IQT optional Ethernet port optional |
Power supply: | AC 220V/20W, or DC 24V/15W solar cell |
Others: | Power outage protection optional Sampling function optional Cleaning function optional Size 200*300*170mm Weight 20.0kg |
