Automatic online testing, loading and unloading
EL:60Megapixels/ VI:240 Megapixels
8 camera array mode
Can detect crack width less than 0.03mm
Automatic Solar Panel EL+AOI Testing Machine
MT-EA008
Features:
1.Our EL and AOI testing machine adapts various specifications and types of components, can be tested online.
2. Automatic loading and unloading, online automatic detection, simple operation.
3. High definition infrared camera, multi camera direct mode, clear imaging.
4. The closed optical path design ensures long-term stable operation of the equipment.
Technical Parameters:
Technical Parameters | |
Model | MT-EA008 |
Resolution | EL:60Megapixels/VI:240 Megapixels |
Shooting mode | 8 camera array mode |
Applicable process | Pre - and post lamination component testing |
Sensitivity | Can detect crack width less than 0.03mm |
Loading method | Automatic loading and unloading |
Detection method | Online automatic detection |
Effective test area | 2600*1500mm |
Image acquisition tine | 100~700ms (adjustable) |
Power Supply | 220V 50HZ |
Machine Size | 3095x2220x1665MM |
